Radar Distance Detector
Radar Distance Detector for Overhead Safety in Elevated Work Platforms
Accurate Obstacle Detection: Radar sensor detects overhead obstacles during lift operations.
Real-Time Alerts: Immediate audio-visual warnings for potential collision risks.
Wireless Communication: UWB technology enables seamless sensor and alarm connectivity.
Emergency Shutdown Capability: Automatically halts lift to prevent imminent collisions.
Easy Installation: Magnetic mounts allow quick, non-invasive system setup.
Radar Distance Detector
The B•SAFE Radar Distance Detector enhances overhead safety during lift, scissor lift, and MEWP operations. Using UWB radar technology, it accurately detects obstacles up to 7 meters away, triggering real-time audio-visual alerts. With a rugged IP65 waterproof design, built-in 1800mAh rechargeable battery (up to 146 hours standby), and easy magnetic mounting, it’s perfect for construction sites, warehouses, airports, malls, and public infrastructure projects—providing an essential layer of collision prevention for working at heights.
| Details | |
|---|---|
| Model Name | BST-9968 |
| Frequency | 802.15.4a UWB / 3.25GHz–6.75GHz |
| Environmental Rating | IP65 |
| Power Type | Built-in 1800mAh battery |
| Battery Lifetime* | Standby Mode: 146 hrs. |
| Dimension | 100 × 68 × 50 mm |
| Weight | 300 g |
| Detection Distance | 7m |
| Type Approval | Pending |
| Button Type | Power ON/OFF, Settings ON/OFF |
| Deployment Scenarios | Construction Sites, Warehouses, Factories, Airports, Shopping Malls, Stadiums & Arenas, Public Infrastructure, Theaters & Event Venues. |
| Where to Install | Handle or guardrail of a lift or scissor lift with an external mount with magnetic attachment. |
